Mã hàng | Thông số |
Vacuum Contactor 3.6/7.2kV 200A, Continuously Energized, Fixed type |
UVC32CX1000000H | 3.6kV, 200A, without fuse holder,
AC/DC 200-230V, 3NO+2NC |
UVC62CX1000000H | 7.2kV, 200A, without fuse holder,
AC/DC 200-230V, 3NO+2NC |
UVC32CA1006000HCM | 3.6kV, 200A, with 192mm single fuse holder not including fuse, AC/DC 200-230V, 3NO+2NC, with FMD |
UVC62CA1006000HCM | 7.2kV, 200A, with 192mm single fuse holder not including fuse, AC/DC 200-230V, 3NO+2NC, with FMD |
Vacuum Contactor 3.6/7.2kV 200A, Continuously Energized, Draw-out type |
UVC32CB1F10000H | 3.6kV, 200A, without fuse holder, AC/DC 200-230V, 3NO+2NC, With F Cradle (Insulation shutter) |
UVC62CB1F10000H | 7.2kV, 200A, without fuse holder, AC/DC 200-230V, 3NO+2NC, With F Cradle (Insulation shutter) |
UVC32CD1F16000CM | 3.6kV, 200A, with 192mm single fuse holder not including fuse, AC/DC 200-230V, 3NO+2NC, With F Cradle (Insulation shutter), with FMD |
UVC62CD1F16000CM | 7.2kV, 200A, with 192mm single fuse holder not including fuse, AC/DC 200-230V, 3NO+2NC, With F Cradle (Insulation shutter), with FMD |
HCA32CB4M10000 | 3.6kV, 200A, without fuse holder, AC220V, 2NO+2NC, With M Cradle (Metal shutter and bushing) |
HCA62CB4M10000 | 7.2kV, 200A, without fuse holder, AC220V, 2NO+2NC, With M Cradle (Metal shutter and bushing) |
HCA32CD4M16000AM | 3.6kV, 200A, with 192mm single fuse holder not including fuse, AC220V, 2NO+2NC, With M Cradle (Metal shutter and bushing), with FMD |
HCA62CD4M16000AM | 7.2kV, 200A, with 192mm single fuse holder not including fuse, AC220V, 2NO+2NC, With M Cradle (Metal shutter and bushing), with FMD |
HCA32CB4T10000 | 3.6kV, 200A, without fuse holder, AC220V, 2NO+2NC, With T Cradle (Metal shutter, Bushing, & Earthing swtich) |
HCA62CB4T10000 | 7.2kV, 200A, without fuse holder, AC220V, 2NO+2NC, With T Cradle (Metal shutter, Bushing, & Earthing swtich) |
Vacuum Contactor 3.6/7.2kV 400A, Continuously Energized, Fixed type |
UVC34CX1000000H | 3.6kV, 400A, without fuse holder,
AC/DC 200-230V, 3NO+2NC |
UVC64CX1000000H | 7.2kV, 400A, without fuse holder,
AC/DC 200-230V, 3NO+2NC |
UVC34CA1006000HCM | 3.6kV, 400A, with 192mm single fuse holder not including fuse,
AC/DC 200-230V, 3NO+2NC, with FMD |
UVC64CA1006000HCM | 7.2kV, 400A, with 192mm single fuse holder not including fuse,
AC/DC 200-230V, 3NO+2NC, with FMD |
Vacuum Contactor 3.6/7.2kV 400A, Continuously Energized, Draw-out type |
UVC34CB1F10000H | 3.6kV, 400A, without fuse holder, AC/DC 200-230V, 3NO+2NC,
With F Cradle (Insulation shutter) |
UVC64CB1F10000H | 7.2kV, 400A, without fuse holder, AC/DC 200-230V, 3NO+2NC,
With F Cradle (Insulation shutter) |
UVC34CD1F16000CM | 3.6kV, 400A, with 192mm single fuse holder not including fuse, AC/DC 200-230V, 3NO+2NC, With F Cradle (Insulation shutter), with FMD |
UVC64CD1F16000CM | 7.2kV, 400A, with 192mm single fuse holder not including fuse, AC/DC 200-230V, 3NO+2NC, With F Cradle (Insulation shutter), with FMD |
HCA34CB4M10000 | 3.6kV, 400A, without fuse holder, AC220V, 2NO+2NC, With M Cradle (Metal shutter and bushing) |
HCA64CB4M10000 | 7.2kV, 400A, without fuse holder, AC220V, 2NO+2NC, With M Cradle (Metal shutter and bushing) |
HCA34CD4M16000AM | 3.6kV, 400A, with 192mm single fuse holder not including fuse, AC220V, 2NO+2NC, With M Cradle (Metal shutter and bushing), with FMD |
HCA64CD4M16000AM | 7.2kV, 400A, with 192mm single fuse holder not including fuse, AC220V, 2NO+2NC, With M Cradle (Metal shutter and bushing), with FMD |
HCA34CB4T10000 | 3.6kV, 400A, without fuse holder, AC220V, 2NO+2NC, With T Cradle (Metal shutter, Bushing, & Earthing swtich) |
HCA64CB4T10000 | 7.2kV, 400A, without fuse holder, AC220V, 2NO+2NC, With T Cradle (Metal shutter, Bushing, & Earthing swtich) |
HCA34CD4T16000AM | 3.6kV, 400A, with 192mm single fuse holder not including fuse, AC220V, 2NO+2NC, With T Cradle (Metal shutter, Bushing, & Earthing swtich), with FMD |
HCA64CD4T16000AM | 7.2kV, 400A, with 192mm single fuse holder not including fuse, AC220V, 2NO+2NC, With T Cradle (Metal shutter, Bushing, & Earthing swtich), with FMD |
